Arduino Nano ESP32 - DHT11 - LCD

This tutorial instructs you how to program Arduino Nano ESP32 to read temperature and humidity from DHT11 and display them on LCD I2C.

Hardware Preparation

1×Arduino Nano ESP32
1×USB Cable Type-C
1×LCD I2C 16x2
1×DHT11 Temperature and Humidity Sensor
1×DHT11 Temperature Humidity Sensor Module (short)
1×Breadboard
1×Jumper Wires
1×(Optional) DC Power Jack
1×(Recommended) Screw Terminal Expansion Board for Arduino Nano
1×(Recommended) Breakout Expansion Board for Arduino Nano

Or you can buy the following sensor kits:

1×DIYables Sensor Kit (30 sensors/displays)
1×DIYables Sensor Kit (18 sensors/displays)
Disclosure: Some of the links provided in this section are Amazon affiliate links. We may receive a commission for any purchases made through these links at no additional cost to you.
Additionally, some of these links are for products from our own brand, DIYables.

Overview of DHT11 and LCD

We have specific tutorials about DHT11 sensor and LCD. Each tutorial contains detailed information and step-by-step instructions about hardware pinout, working principle, wiring connection to ESP32, Arduino Nano ESP32 code... Learn more about them at the following links:

Wiring Diagram

The wiring diagram between Arduino Nano ESP32 and DHT11 LCD I2C

This image is created using Fritzing. Click to enlarge image

Arduino Nano ESP32 Code - DHT11 Sensor - LCD I2C

/* * This Arduino Nano ESP32 code was developed by newbiely.com * * This Arduino Nano ESP32 code is made available for public use without any restriction * * For comprehensive instructions and wiring diagrams, please visit: * https://newbiely.com/tutorials/arduino-nano-esp32/arduino-nano-esp32-dht11-lcd */ #include <DHT.h> #include <LiquidCrystal_I2C.h> #define DHT11_PIN D2 // The Arduino Nano ESP32 pin connected to DHT11 sensor LiquidCrystal_I2C lcd(0x27, 16, 2); // I2C address 0x27 (from DIYables LCD), 16 column and 2 rows DHT dht11(DHT11_PIN, DHT11); void setup() { dht11.begin(); // initialize the DHT11 sensor lcd.init(); // initialize the lcd lcd.backlight(); // open the backlight } void loop() { float humidity = dht11.readHumidity(); // read humidity float temperature = dht11.readTemperature(); // read temperature lcd.clear(); // check whether the reading is successful or not if (isnan(temperature) || isnan(humidity)) { lcd.setCursor(0, 0); lcd.print("Failed"); } else { lcd.setCursor(0, 0); // display position lcd.print("Temp: "); lcd.print(temperature); // display the temperature lcd.print("°C"); lcd.setCursor(0, 1); // display position lcd.print("Humi: "); lcd.print(humidity); // display the humidity lcd.print("%"); } // wait a 2 seconds between readings delay(2000); }

※ NOTE THAT:

The LCD I2C address can be different from each manufacturer. In the code, we used address of 0x27 that is specified by DIYables manufacturer

Detailed Instructions

To get started with Arduino Nano ESP32, follow these steps:

  • If you are new to Arduino Nano ESP32, refer to the tutorial on how to set up the environment for Arduino Nano ESP32 in the Arduino IDE.
  • Wire the components according to the provided diagram.
  • Connect the Arduino Nano ESP32 board to your computer using a USB cable.
  • Launch the Arduino IDE on your computer.
  • Select the Arduino Nano ESP32 board and its corresponding COM port.* Click to the Libraries icon on the left bar of the Arduino IDE.
  • Type “DHT” on the search box, then look for the DHT sensor library by Adafruit
  • Install the library by clicking on Install button.
Arduino Nano ESP32 DHT sensor library
  • A windows appears to ask you to install dependencies for the library
  • Install all dependencies for the library by clicking on Install All button.
Arduino Nano ESP32 Adafruit Unified sensor library
  • Type “LiquidCrystal I2C” on the search box, then look for the LiquidCrystal_I2C library by Frank de Brabander
  • Click Install button to install LiquidCrystal_I2C library.
Arduino Nano ESP32 LiquidCrystal I2C library
  • Copy the above code and paste it to Arduino IDE.
  • Compile and upload code to Arduino Nano ESP32 board by clicking Upload button on Arduino IDE
  • Make the sensor colder or hotter. For example, putting the sensor near a hot cup of coffee
  • See the result in LCD

If LCD displays nothing, see Troubleshooting on LCD I2C

Video Tutorial
