ESP32 S3 UNO - DIYables Bluetooth App Analog Gauge

Overview

This ESP32 S3 Uno Bluetooth analog gauge tutorial shows you how to send live numbers from the ESP32 S3 Uno form board to a dial meter on your smartphone. The gauge lives in the DIYables Bluetooth STEM app and talks to the board over BLE (Bluetooth Low Energy). You set the range and the unit, so the same BLE gauge can act as a speedometer, a voltmeter or a pressure meter.

In this tutorial, you will:

Install the DIYables Bluetooth library in Arduino IDE
Upload a BLE analog gauge sketch to the ESP32 S3 Uno
Connect the DIYables Bluetooth app on Android or iOS and watch the needle move
Change the gauge range and unit for your own sensor
Build real meters like a voltmeter, a pressure gauge and a speedometer

※ NOTE THAT:

The ESP32 S3 Uno supports only BLE. It has no Classic Bluetooth, so the Classic (BluetoothSerial) version of this example does not run on it. That is good news for you: BLE works with the app on both Android and iOS, and you do not need to pair the board first.

Features

The gauge app gives you a ready-made dial screen, so you only have to send numbers. Here is what you get out of the box.

Classic dial display

A needle moves across a graduated scale, like a real analog meter. The exact value is also shown as a number.

Your own range and unit

You choose the minimum, the maximum and the unit text, such as km/h, PSI, V or %. You can change all three while the sketch is running.

Live updates

The sketch sends a new value every 200 ms, so the needle moves smoothly. The app can also ask the board for the current value at any time.

BLE on Android and iOS

BLE uses little power and needs no manual pairing. The same sketch works with both phone platforms.

Hardware Preparation

1	×	ESP32 S3 Uno-form Board
1	×	USB Cable Type-A to Type-C (for USB-A PC)
1	×	USB Cable Type-C to Type-C (for USB-C PC)
1	×	Breadboard
1	×	Jumper Wires

Or you can buy the following kits:

DIYables Sensor Kit (18 sensors/displays)

Disclosure: Some of the links provided in this section are Amazon affiliate links. We may receive a commission for any purchases made through these links at no additional cost to you.
Additionally, some of these links are for products from our own brand, DIYables .

ESP32 S3 Uno Code

The main sketch does not need any sensor. It makes a smooth sine wave from 0 to 100 and sends it to the gauge, so you can test the app first and add a real sensor later.

Detailed Instructions

New to the ESP32 S3 Uno? Follow ESP32 S3 Uno - Getting Started first.
Connect the board to your computer with a USB Type-C cable.
Open Arduino IDE, choose the ESP32S3 Dev Module board and the correct COM port.
Pick a big partition: go to Tools > Partition Scheme and select Huge APP (3MB No OTA/1MB SPIFFS). The Bluetooth library is large and does not fit in the default space.
Open the library manager: click the Libraries icon on the left bar of Arduino IDE.
Find the library: search "DIYables Bluetooth" and find the DIYables Bluetooth library by DIYables.
Install it: click the Install button.

Search for DIYables Bluetooth created by DIYables and click the Install button.

Newbiely | Arduino IDE 2.3.8

──

☐

Library Manager

DIYables Bluetooth

All

DIYables Bluetooth by DIYables

A comprehensive Bluetooth library that connects Arduino to the DIYables Bluetooth STEM mobile app (Android & iOS) via BLE and Classic Bluetooth. Features 11 built-in apps: Monitor, Chat, Digital Pin Control, Joystick, Sliders, Plotter, Analog Gauge, Rotator, Temperature, RTC, and Data Table. Clean architecture with platform abstraction. Works with Arduino Uno R4 WiFi, Arduino Nano 33 BLE, ESP32, and other BLE-capable boards. No mobile coding required. More info

1.0.1

INSTALL

Newbiely.ino

···

1 void setup() {

Output

Serial Monitor

Ln 1, Col 1

ESP32S3 Dev Module on COM15

Install the dependencies: Arduino IDE asks to add some other libraries. Click Install All.
Tip: if the upload does not start, hold the BOOT button, press RESET, then release BOOT and try again.

ESP32 S3 Uno BLE Code (works with the app on Android and iOS)

The sketch starts a BLE server named "ESP32BLE_Gauge" and adds the analog gauge app with a 0 to 100 km/h range. When a phone connects, it sends a value every 200 ms and prints it to the Serial Monitor. The ANALOG_PIN line already points to A0 (GPIO2), ready for a real sensor.

Load the code: in Arduino IDE go to File Examples DIYables Bluetooth Esp32BLE_AnalogGauge, or copy the code below into the editor.

/* * This ESP32 S3 Uno code was developed by newbiely.com * * This ESP32 S3 Uno code is made available for public use without any restriction * * For comprehensive instructions and wiring diagrams, please visit: * https://newbiely.com/tutorials/esp32-s3-uno/esp32-s3-uno-diyables-bluetooth-app-analog-gauge */ /* * DIYables Bluetooth Library - ESP32 S3 Uno BLE Analog Gauge Example * Works with DIYables Bluetooth STEM app on Android and iOS * * This example demonstrates the Bluetooth Analog Gauge feature: * - Display values on an analog meter/gauge * - Configurable range and unit * - Perfect for sensor monitoring (speed, pressure, voltage, etc.) * * Board: ESP32 S3 Uno form board (BLE only, no Classic Bluetooth) * * Note: Select "Huge APP (3MB No OTA/1MB SPIFFS)" partition scheme * in Arduino IDE: Tools > Partition Scheme * * Optional: Analog sensor (potentiometer, pressure sensor, etc.) on A0 (GPIO2) * * Setup: * 1. Upload the sketch to your ESP32 S3 Uno * 2. Open Serial Monitor (115200 baud) to see connection status * 3. Use DIYables Bluetooth App to connect and view the gauge * * Tutorial: https://diyables.io/bluetooth-app * Author: DIYables */ #include <DIYables_BluetoothServer.h> #include <DIYables_BluetoothAnalogGauge.h> #include <platforms/DIYables_Esp32BLE.h> // BLE Configuration const char* DEVICE_NAME = "ESP32BLE_Gauge"; const char* SERVICE_UUID = "19B10000-E8F2-537E-4F6C-D104768A1214"; const char* TX_UUID = "19B10001-E8F2-537E-4F6C-D104768A1214"; const char* RX_UUID = "19B10002-E8F2-537E-4F6C-D104768A1214"; // Create Bluetooth instances DIYables_Esp32BLE bluetooth(DEVICE_NAME, SERVICE_UUID, TX_UUID, RX_UUID); DIYables_BluetoothServer bluetoothServer(bluetooth); // Create Analog Gauge app instance (min=0, max=100, unit="km/h") DIYables_BluetoothAnalogGauge bluetoothGauge(0.0, 100.0, "km/h"); // Variables for gauge value float currentValue = 0.0; unsigned long lastUpdate = 0; const unsigned long UPDATE_INTERVAL = 200; // Update every 200ms // Optional: Analog input pin for sensor const int ANALOG_PIN = 2; // ESP32 S3 Uno A0 (GPIO2) // Function to read sensor value float readSensorValue() { // TODO: Replace with actual sensor reading // Option 1: Read from analog pin and map to gauge range // int rawValue = analogRead(ANALOG_PIN); // return map(rawValue, 0, 4095, 0, 100); // ESP32 S3 Uno has 12-bit ADC // Option 2: Simulated data (sine wave) static float phase = 0; phase += 0.05; if (phase > 2 * PI) phase = 0; return 50 + 50 * sin(phase); // Oscillates between 0-100 } void setup() { Serial.begin(115200); // set the ADC attenuation to 11 dB (up to ~3.3V input) analogSetAttenuation(ADC_11db); delay(1000); Serial.println("DIYables Bluetooth - ESP32 S3 Uno BLE Analog Gauge Example"); // Initialize Bluetooth server with platform-specific implementation bluetoothServer.begin(); // Add gauge app to server bluetoothServer.addApp(&bluetoothGauge); // Set up connection event callbacks bluetoothServer.setOnConnected([]() { Serial.println("Bluetooth connected!"); currentValue = readSensorValue(); bluetoothGauge.send(currentValue); Serial.print("Initial value sent: "); Serial.print(currentValue); Serial.print(" "); Serial.println(bluetoothGauge.getUnit()); }); bluetoothServer.setOnDisconnected([]() { Serial.println("Bluetooth disconnected!"); }); bluetoothGauge.onValueRequest([]() { currentValue = readSensorValue(); bluetoothGauge.send(currentValue); Serial.print("Value requested - Sent: "); Serial.print(currentValue); Serial.print(" "); Serial.println(bluetoothGauge.getUnit()); }); Serial.println("Waiting for Bluetooth connection..."); Serial.print("Gauge range: "); Serial.print(bluetoothGauge.getMin()); Serial.print(" - "); Serial.print(bluetoothGauge.getMax()); Serial.print(" "); Serial.println(bluetoothGauge.getUnit()); } void loop() { bluetoothServer.loop(); if (bluetooth.isConnected() && millis() - lastUpdate >= UPDATE_INTERVAL) { lastUpdate = millis(); currentValue = readSensorValue(); bluetoothGauge.send(currentValue); Serial.print("Gauge: "); Serial.print(currentValue, 1); Serial.print(" "); Serial.println(bluetoothGauge.getUnit()); } delay(10); }

Upload: click the Upload button to send the code to the ESP32 S3 Uno.
Open the Serial Monitor and set it to 115200 baud.
Check the output. You should see something like this:

Newbiely | Arduino IDE 2.3.8

──

☐

Newbiely.ino

···

8 Serial.println("Hello World!");

Output

Serial Monitor

Message (Enter to send message to 'ESP32S3 Dev Module' on 'COM15')

New Line

9600 baud

DIYables Bluetooth - ESP32 S3 Uno BLE Analog Gauge Example Waiting for Bluetooth connection... Gauge range: 0.00 - 100.00 km/h

Ln 11, Col 1

ESP32S3 Dev Module on COM15

Tip: keep the Serial Monitor open. It shows when the phone connects and every value that goes to the gauge.

The setup() function also calls analogSetAttenuation(ADC_11db). By default, the ESP32 S3 Uno ADC can only measure a small voltage. With 11 dB attenuation, an analog pin reads the full range from 0V up to about 3.3V, so a sensor on A0 (GPIO2) uses the whole 0 to 4095 scale. Without it, readings hit 4095 too early and the gauge shows wrong values.

Mobile App

Now you connect your phone. Because the ESP32 S3 Uno uses BLE, there is no pairing step in the phone settings. You only scan and tap in the app.

Install the app: get the DIYables Bluetooth App for Android or iOS.
Open the app and grant the permissions it asks for the first time:

Nearby Devices (Android 12 and newer) or Bluetooth (iOS), to scan and connect to devices
Location (Android 11 and older only), because older Android needs it to scan for BLE devices

Turn on Bluetooth on your phone.

Scan: on the home screen, tap the Connect button.

DIYables Bluetooth App - Home Screen with Scan Button

Connect: tap "ESP32BLE_Gauge" in the scan results. The app goes back to the home screen when the link is ready.
Open the gauge: select the Analog Gauge app from the menu.

DIYables Bluetooth App - Home Screen with Analog Gauge App

Watch the needle: it swings up and down as the sine wave values arrive.

DIYables Bluetooth App - Analog Gauge Screen

Tip: tap the settings icon on the home screen to hide or show apps. The DIYables Bluetooth App User Manual has more details.

Go back to the Serial Monitor in Arduino IDE. You will see lines like these:

Newbiely | Arduino IDE 2.3.8

──

☐

Newbiely.ino

···

8 Serial.println("Hello World!");

Output

Serial Monitor

Message (Enter to send message to 'ESP32S3 Dev Module' on 'COM15')

New Line

9600 baud

Bluetooth connected! Initial value sent: 52.50 km/h Gauge: 55.0 km/h Gauge: 57.5 km/h Gauge: 59.9 km/h

Ln 11, Col 1

ESP32S3 Dev Module on COM15

Creative Customization - Adapt the Code to Your Project

The example is only a starting point. With a few lines you can turn it into the meter your project needs.

Configure Gauge Range and Unit

You set the range and the unit in the constructor. You can also change them later, for example when the user switches from km/h to MPH.

// Constructor: DIYables_BluetoothAnalogGauge(min, max, unit) DIYables_BluetoothAnalogGauge bluetoothGauge(0.0, 100.0, "km/h"); // Change range at runtime bluetoothGauge.setRange(0.0, 200.0); // Change unit bluetoothGauge.setUnit("MPH"); // Read current configuration float minVal = bluetoothGauge.getMin(); // Returns 0.0 float maxVal = bluetoothGauge.getMax(); // Returns 100.0 String unit = bluetoothGauge.getUnit(); // Returns "km/h"

Send Gauge Value

Call send() with a number to move the needle. You can also send a short text, which is handy while the sensor warms up.

// Send current reading float speed = 72.5; bluetoothGauge.send(speed); // Send text message bluetoothGauge.send("Calibrating...");

Handle Value Requests from App

The app can ask for the latest value, for example right after the gauge screen opens. This callback reads your sensor and answers at once.

bluetoothGauge.onValueRequest([]() { float currentValue = readSensor(); bluetoothGauge.send(currentValue); Serial.println("App requested value: " + String(currentValue)); });

Handle Connection Events

These two callbacks run when the phone connects or leaves. Sending a value on connect means the gauge never starts empty.

bluetoothServer.setOnConnected([]() { Serial.println("Bluetooth connected!"); bluetoothGauge.send(currentValue); // Send current reading }); bluetoothServer.setOnDisconnected([]() { Serial.println("Bluetooth disconnected!"); });

How to Use the Analog Gauge

It helps to know what each part of the screen means, so you can pick a good range and unit.

App Interface

The gauge screen has a dial with a moving needle and scale marks from your minimum to your maximum. Under the dial, a number shows the exact value, next to the unit text you set in the code.

Common Unit Configurations

Use	Constructor
Speed	DIYables_BluetoothAnalogGauge(0.0, 200.0, "km/h")
Pressure	DIYables_BluetoothAnalogGauge(0.0, 100.0, "PSI")
Voltage	DIYables_BluetoothAnalogGauge(0.0, 3.3, "V")
Percentage	DIYables_BluetoothAnalogGauge(0.0, 100.0, "%")
RPM	DIYables_BluetoothAnalogGauge(0.0, 8000.0, "RPM")

ESP32 S3 Uno Pinout

The examples below connect sensors to the board. The image shows the ESP32 S3 Uno form board pinout, so you can find the Uno header pins (A0, D2, SDA, SCL) and their GPIO numbers.

Programming Examples

Each example shows only the parts that change. Keep the BLE setup lines from the main sketch, including analogSetAttenuation(ADC_11db) in setup() for the analog examples.

Voltage Meter

This meter reads a voltage divider on A0 (GPIO2). A 5:1 divider turns up to 16V into about 3.2V, which is safe for the 3.3V ESP32 S3 Uno input.

Component Pin	ESP32 S3 Uno Pin
Divider output	A0 (GPIO2)
Divider GND	GND

const int VOLTAGE_PIN = 2; // A0 (GPIO2) const float VREF = 3.3; const float DIVIDER_RATIO = 5.0; // Voltage divider ratio // Gauge configured for 0-16V range DIYables_BluetoothAnalogGauge bluetoothGauge(0.0, 16.0, "V"); void loop() { bluetoothServer.loop(); static unsigned long lastUpdate = 0; if (millis() - lastUpdate >= 500) { lastUpdate = millis(); int raw = analogRead(VOLTAGE_PIN); float voltage = (raw / 4095.0) * VREF * DIVIDER_RATIO; bluetoothGauge.send(voltage); Serial.println("Voltage: " + String(voltage, 2) + " V"); } delay(10); }

Pressure Gauge (BMP280)

The BMP280 talks over I2C. On the ESP32 S3 Uno, A4 and A5 are not I2C pins, so wire the sensor to the SDA (GPIO8) and SCL (GPIO9) header pins. Wire.begin() uses them by default.

BMP280 Pin	ESP32 S3 Uno Pin
VCC	3.3V
GND	GND
SDA	SDA (GPIO8)
SCL	SCL (GPIO9)

#include <Adafruit_BMP280.h> Adafruit_BMP280 bmp; // Gauge configured for atmospheric pressure range DIYables_BluetoothAnalogGauge bluetoothGauge(900.0, 1100.0, "hPa"); void setup() { Serial.begin(115200); bmp.begin(0x76); // ... Bluetooth setup ... bluetoothGauge.onValueRequest([]() { float pressure = bmp.readPressure() / 100.0; // Pa to hPa bluetoothGauge.send(pressure); }); } void loop() { bluetoothServer.loop(); static unsigned long lastUpdate = 0; if (millis() - lastUpdate >= 1000) { lastUpdate = millis(); float pressure = bmp.readPressure() / 100.0; bluetoothGauge.send(pressure); Serial.println("Pressure: " + String(pressure, 1) + " hPa"); } delay(10); }

Current Sensor (ACS712)

The ACS712 output goes to A0 (GPIO2). The code uses the 185 mV/A sensitivity of the 5A version and a 2.5V zero point.

The ACS712 is a 5V module. Its output sits at 2.5V with no current and can go above 3.3V at high current, which can damage the ESP32 S3 Uno pin. Keep the current small, or add a voltage divider between the sensor output and A0, and change ZERO_CURRENT_VOLTAGE and SENSITIVITY to match.

const int CURRENT_PIN = 2; // A0 (GPIO2) const float SENSITIVITY = 0.185; // ACS712-05B: 185mV/A const float ZERO_CURRENT_VOLTAGE = 2.5; // Gauge configured for 0-5A range DIYables_BluetoothAnalogGauge bluetoothGauge(0.0, 5.0, "A"); void loop() { bluetoothServer.loop(); static unsigned long lastUpdate = 0; if (millis() - lastUpdate >= 200) { lastUpdate = millis(); int raw = analogRead(CURRENT_PIN); float voltage = (raw / 4095.0) * 3.3; float current = abs((voltage - ZERO_CURRENT_VOLTAGE) / SENSITIVITY); bluetoothGauge.send(current); Serial.println("Current: " + String(current, 2) + " A"); } delay(10); }

Speed from Encoder

An encoder or a slotted wheel gives one pulse per slot. An interrupt counts the pulses on D2 (GPIO18), and the sketch turns them into km/h every 500 ms.

Encoder Pin	ESP32 S3 Uno Pin
VCC	3.3V
GND	GND
OUT	D2 (GPIO18)

volatile unsigned long pulseCount = 0; const int ENCODER_PIN = 18; // D2 (GPIO18) const float PULSES_PER_REV = 20.0; const float WHEEL_CIRCUMFERENCE = 0.628; // meters (20cm diameter) DIYables_BluetoothAnalogGauge bluetoothGauge(0.0, 50.0, "km/h"); void IRAM_ATTR countPulse() { pulseCount++; } void setup() { Serial.begin(115200); pinMode(ENCODER_PIN, INPUT_PULLUP); attachInterrupt(digitalPinToInterrupt(ENCODER_PIN), countPulse, RISING); // ... Bluetooth setup ... } void loop() { bluetoothServer.loop(); static unsigned long lastCalc = 0; if (millis() - lastCalc >= 500) { unsigned long elapsed = millis() - lastCalc; lastCalc = millis(); noInterrupts(); unsigned long count = pulseCount; pulseCount = 0; interrupts(); float revPerSec = (count / PULSES_PER_REV) / (elapsed / 1000.0); float speedKmh = revPerSec * WHEEL_CIRCUMFERENCE * 3.6; bluetoothGauge.send(speedKmh); Serial.println("Speed: " + String(speedKmh, 1) + " km/h"); } delay(10); }

Advanced Programming Techniques

Raw sensor values are often noisy. These small helpers make the gauge easier to read.

Smooth Needle Movement

A simple filter moves the shown value only part of the way toward the new reading each time. A lower SMOOTHING number gives a calmer needle.

float displayValue = 0; float targetValue = 0; const float SMOOTHING = 0.1; // 0.0-1.0, lower = smoother void loop() { bluetoothServer.loop(); static unsigned long lastUpdate = 0; if (millis() - lastUpdate >= 50) { // 20 FPS lastUpdate = millis(); targetValue = readSensor(); displayValue += (targetValue - displayValue) * SMOOTHING; bluetoothGauge.send(displayValue); } delay(5); }

Peak Hold

Peak hold keeps the highest value on the dial for 3 seconds. You can then see short spikes that would otherwise flash by.

float peakValue = 0; unsigned long peakTime = 0; const unsigned long PEAK_HOLD_MS = 3000; // Hold peak for 3 seconds void updateWithPeakHold(float value) { if (value > peakValue) { peakValue = value; peakTime = millis(); } if (millis() - peakTime > PEAK_HOLD_MS) { peakValue = value; // Reset peak } // Send the higher of current or peak bluetoothGauge.send(max(value, peakValue)); }

Range Auto-Scaling

If you do not know the sensor range yet, let the code widen the scale when a value goes past the edge.

float autoMin = 0; float autoMax = 100; void autoScale(float value) { bool changed = false; if (value < autoMin) { autoMin = value - 10; changed = true; } if (value > autoMax) { autoMax = value + 10; changed = true; } if (changed) { bluetoothGauge.setRange(autoMin, autoMax); } bluetoothGauge.send(value); }

Hardware Integration Ideas

Almost any sensor that gives a number can drive the gauge. Keep every signal that goes into the ESP32 S3 Uno at 3.3V or less.

Analog sensors

Potentiometers, force sensors and flex sensors work on the analog pins, such as A0 (GPIO2). The 12-bit ADC gives values from 0 to 4095.

I2C and SPI sensors

Use I2C sensors like the BMP280 (pressure) or INA219 (current and power) on SDA (GPIO8) and SCL (GPIO9). SPI sensors use D10 to D13, which match the default SPI pins.

Pulse and frequency sensors

Speed encoders, flow meters and RPM sensors work well with interrupt-based counting on a digital pin.

Load cells (HX711)

The HX711 amplifier lets you build a kitchen scale or a weighing station with a gauge display.

Bluetooth Mode on the ESP32 S3 Uno

The chip on the ESP32 S3 Uno has only BLE. Some other boards also offer Classic Bluetooth, but the Classic version of this example does not work here. The table shows what BLE gives you.

Feature	ESP32 S3 Uno (BLE, Esp32BLE_AnalogGauge)
iOS support	Yes
Android support	Yes
Power use	Low
Range	About 30 to 100 m in open space
Pairing	Not needed, scan and connect in the app
Classic Bluetooth (BluetoothSerial)	Not supported by the chip

Debug Tips

When the needle shows something odd, print the value, the range and the percentage. This small function puts everything in the Serial Monitor so you can compare it with the app.

void debugGauge(float value) { Serial.println("=== Gauge Debug ==="); Serial.println("Value: " + String(value, 2) + " " + bluetoothGauge.getUnit()); Serial.println("Range: " + String(bluetoothGauge.getMin(), 1) + " - " + String(bluetoothGauge.getMax(), 1)); Serial.println("In Range: " + String(value >= bluetoothGauge.getMin() && value <= bluetoothGauge.getMax() ? "Yes" : "No")); float percentage = (value - bluetoothGauge.getMin()) / (bluetoothGauge.getMax() - bluetoothGauge.getMin()) * 100.0; Serial.println("Percentage: " + String(percentage, 1) + "%"); Serial.println("==================="); }

Project Ideas

Need some inspiration? These projects all fit the gauge display well.

Vehicle and motion

A speedometer for an RC car or a bicycle, an RPM meter for motors, a G-force meter or a tilt angle indicator.

Electrical and power

A battery voltmeter, an ammeter for current use, a wattmeter or a battery level gauge.

Environment

A barometric pressure gauge, a wind speed meter, a UV index meter or a sound level meter.

Industrial

A weight scale, a flow rate meter, a tank level indicator or a torque meter.

Integration with Other Bluetooth Apps

The gauge works well next to other DIYables Bluetooth apps. One server can run several apps at once.

Combine with Bluetooth Temperature

Show pressure on the gauge and temperature on its own screen.

// Gauge shows pressure bluetoothGauge.send(pressure); // Temperature shows temperature bluetoothTemperature.send(temperature);

Combine with Bluetooth Table

Use the gauge for a quick look and a table for the details.

float speed = readSpeed(); bluetoothGauge.send(speed); bluetoothTable.sendValueUpdate("Speed", String(speed, 1) + " km/h"); bluetoothTable.sendValueUpdate("Distance", String(totalDistance, 2) + " km"); bluetoothTable.sendValueUpdate("Max Speed", String(maxSpeed, 1) + " km/h"); bluetoothTable.sendValueUpdate("Avg Speed", String(avgSpeed, 1) + " km/h");

Next Steps

Once the gauge works on your ESP32 S3 Uno, try these examples next:

Bluetooth Temperature - a display made for temperature
Bluetooth Plotter - to see how a value changes over time
Bluetooth Table - to show many values in rows
Multiple Bluetooth Apps - to combine the gauge with other screens

Support

If you get stuck, these places can help:

The API reference that comes with the DIYables Bluetooth library
The DIYables Bluetooth App tutorials
The Arduino community forums

FAQ

Why is there no Classic Bluetooth code for the ESP32 S3 Uno?

The chip on the ESP32 S3 Uno has only BLE (Bluetooth Low Energy). BluetoothSerial and other Classic Bluetooth code will not compile or run on it. Use the Esp32BLE_AnalogGauge example. It works with the app on Android and iOS.

Do I need a sensor to try the ESP32 S3 Uno Bluetooth gauge?

No. The main sketch makes a sine wave from 0 to 100, so the needle moves without any wiring. When you are ready, uncomment the analogRead() lines in readSensorValue() and connect your sensor to A0 (GPIO2).

Why does the code call analogSetAttenuation(ADC_11db)?

It sets the ESP32 S3 Uno ADC input range to about 0 to 3.3V, so the full sensor signal maps to 0 to 4095. Without it the range is smaller and readings saturate early. The UNO R4 does not need this line, because it is only for the ESP32 family. Keep the sensor output at 3.3V or less.

Can I connect a 5V sensor output to the ESP32 S3 Uno?

Not directly. The ESP32 S3 Uno pins are 3.3V logic and are not 5V tolerant. Use a voltage divider or a level shifter between a 5V output and the pin, and change the math in the code to match.

Why do I get "Sketch too big" when I upload?

The Bluetooth stack needs a lot of flash. Go to Tools > Partition Scheme and choose "Huge APP (3MB No OTA/1MB SPIFFS)". Then upload again.

What if my project needs more pins than the Uno headers give?

The ESP32 S3 Uno has two extra rows of holes with more GPIOs: GPIO15 and GPIO16 (I/O, PWM, analog), GPIO45 and GPIO35 to GPIO42 (I/O, PWM), and GPIO47 and GPIO48 (output only, PWM). Solder pin headers to use them and write the GPIO number in code. For a second analog sensor on another gauge, GPIO15 or GPIO16 is the best choice; for encoder inputs, use GPIO35 to GPIO42, not GPIO47 or GPIO48. Be careful with two things. First, GPIO47 and GPIO48 may run at 1.8V instead of 3.3V on some modules (especially ones with "V" in the name, like R8V or R16V), so 3.3V devices can be damaged or act strangely. Second, GPIO0, GPIO3 (D6), GPIO45 and GPIO46 (D9) are boot strapping pins, and a wrong connection can stop the board from booting or uploading code. Use the other extra pins first.

Troubleshooting

Problem	Possible Cause	Solution
No COM port in Arduino IDE	USB driver missing or charge-only cable	Install the CP210x or CH340 driver, use a data USB Type-C cable, or hold BOOT while pressing RESET
Sketch too big error	Default partition is too small for Bluetooth	Select Tools > Partition Scheme > Huge APP (3MB No OTA/1MB SPIFFS)
ESP32BLE_Gauge does not show in the app	Board not powered, sketch not uploaded, or phone Bluetooth off	Check the Serial Monitor for "Waiting for Bluetooth connection...", turn on Bluetooth, and on Android 11 or older turn on Location
Classic Bluetooth code fails to compile	The ESP32 S3 Uno has no Classic Bluetooth	Use the BLE example Esp32BLE_AnalogGauge instead of the BluetoothSerial one
Gauge stuck at 0 or wrong value	Sensor wiring wrong or value out of range	Check the wiring to A0 (GPIO2), print the value in the Serial Monitor, and fix the range with setRange()
Gauge always shows the maximum	Analog input above 3.3V or no ADC attenuation	Keep the signal at 3.3V or less with a divider, and keep analogSetAttenuation(ADC_11db) in setup()
Needle jumps around	Noisy sensor or floating analog pin	Add the smoothing filter, average several readings, and make sure the sensor GND is connected
Connection drops often	Phone too far away or weak USB power	Move the phone closer and use a good USB cable or power supply

Learn More

※ OUR MESSAGES

As freelancers, We are AVAILABLE for HIRE. See how to outsource your project to us
Please feel free to share the link of this tutorial. However, Please do not use our content on any other websites. We invested a lot of effort and time to create the content, please respect our work!
